LED Zeus

LED Zeus

Description: Complete range of outdoor and indoor floodlights ideal for lighting car parks, yards, facades, loading-unloading areas, shopping centers and large areas in general.
Installation: on vertical, horizontal and suspended surfaces.
Body and frame: die-cast aluminum UNI 5076 painted with thermosetting polyester powder.
Fixing bracket: steel, painted with thermosetting polyester powder, with graduated goniometer for correct aiming of the light beam.
Painting: polyester powder type, resistant to atmospheric agents, corrosion and salt spray. Gray RAL 9007.
Optic: concentrating, semi concentrating, wide beam, asymmetric and elliptical. In PMMA with resistance to high temperatures, thermal shocks and impacts
Screen : 4mm thick tempered glass resistant to thermal shocks and impacts.
Source: SAMSUNG LED
Minimum luminous flux maintenance at 90% - 100,000h (L90B10) for 90% of LEDs.
Color temperature: 4000K; other color temperatures on request (2200K - 2700K - 3000K - 5000K - Delivery: 60 days).
Driver: built-in ENEC.
Power factor: ≥0.95.
Surge protection included:
Differential mode 6kV (LN)
8kV common mode (L-GND, N-GND, L & N-GND)
On request: version with increased protection (10kV) against impulses by adding cod. RO0640 / N.
Reference standards : EN60598-1; EN60598-2-1; EN62471; EN62031; EN60598-2-5; EN61547
